Proprietary Carbon-Free Dielectric Isolation The SKW series is engineered with a specialized carbon-free EPDM formulation, making it the premier non-conductive rubber hose for sensitive electronics. It offers an exceptional dielectric strength of up to 6000V, effectively preventing stray currents and electrolytic corrosion within the liquid cooling loop, which is critical for safeguarding expensive GPU and CPU cores.
Optimized Flexibility for High-Density Rack Cabling Designed specifically for the confined spaces of modern AI server racks, this hose maintains a tight bend radius even under its robust 300PSI working pressure. Its superior flexibility allows for complex routing between the server manifold and cold plates without kinking or restricting the critical flow of coolant.
Superior Compatibility with CDU Secondary Loop Fluids Built to support sustainable data center liquid cooling, the SKW hose offers excellent chemical compatibility with deionized water and glycol-based mixtures. The smooth, non-reactive inner tube ensures a clean secondary loop system, preventing scale buildup and maintaining the thermal efficiency of the entire heat dissipation infrastructure.
Heavy-Duty Durability with Extreme Temperature Stability Reinforced with high-tensile polyester fiber, the hose remains structurally sound across a wide temperature spectrum from -40°C to 120°C. Its exceptional ozone and aging resistance make it a "set-and-forget" solution, ensuring the long-term reliability and uptime required for 24/7 mission-critical operations.
AI Data Center and Server Rack Cooling The ideal interface for direct-to-chip cooling systems, connecting the manifold to the cold plate. It provides the non-conductive fluid path necessary for the safe and efficient thermal management of high-wattage computing nodes.
Secondary Loop Connections in CDU Systems Serves as the high-reliability conduit between the Cooling Distribution Unit (CDU) and the server cabinets. Its dielectric properties and high pressure rating make it the trusted choice for large-scale liquid cooling deployments.
HPC (High-Performance Computing) Cooling Networks Optimized for the massive heat loads of supercomputing and AI clusters, this liquid cooling hose delivers the high-flow, low-pressure-drop performance required to maintain peak processing speeds.
Thermal Management for Industrial Power Electronics Beyond IT, the SKW series is perfectly suited for cooling water-cooled cables in induction furnaces, power converters, and energy storage systems (BESS) where high-insulation rubber hoses are mandatory to prevent electrical leakage.
Compatible with our SLQC Liquid Cooling QDs for a complete leak-proof CDU solution.
Q1: Why must "carbon-free" hoses be used in liquid-cooled servers?
A1: Standard rubber hoses with carbon black fillers are slightly conductive. Over time, this causes electrolytic corrosion and leaks. Our SKW carbon-free hose is designed for data center liquid cooling, protecting sensitive electronics from electrical interference.
Q2: What is the maximum pressure this liquid cooling hose can handle?
A2: The series supports a continuous 300PSI (20 bar) working pressure, with burst pressures up to 1200PSI, meeting the rigorous safety standards of major CDU secondary loop systems.
Q3: Is the hose compatible with standard coolants?
A3: Yes. The SKW EPDM Cooling Hose is specifically formulated for compatibility with glycol-water mixtures and deionized water, making it the most reliable solution for global cold plate cooling systems.
